RF-GUV1201

In-line control unit

# Component Description

3.5mm cable jack Plug the black 3.5mm cable into this jack and into

the LINE IN jack on your headset.

Mute indicator Lights red when all audio and chat is muted. (The

ALL MUTE button is on the headset.) Lights yellow

when the microphone is muted.

BASS Rotate to adjust the bass.

VOLUME Rotate to adjust the overall volume.

SRS switch Slide this switch to turn the SRS sound feature on or

off.

CHAT/GAME

VOLUME balance

Rotate to adjust the balance between the chat and

game volume.

MIC MUTE Press to mute the microphone. Press again to

un-mute the microphone.

Xbox 360 chat cable

jack

Plug the 2.5mm Xbox 360 chat cable into this jack

and into the jack on the Xbox 360 controller.
